Geberit Sigma 12cm Concealed Dual Flush Cistern with Geberit Sigma 20 - Gloss Chrome Flush Plate
The Geberit Sigma 12cm Concealed Cistern is specifically designed for easy installation in part-height or room-height prewalls or partition walls. With a construction height of 108cm, it pairs seamlessly with back-to-wall floor-standing toilet pans. Notable features include adjustable flush volume settings (6-liter and 3-liter flush or 4.5-liter and 3-liter flush), condensation insulation, flexible water supply connection options (rear or top center), seawater resistance, a protective cover box for the service opening, immediate post-flush capability, and compatibility with filter systems for rainwater use. As for the Geberit Sigma 20 Flush Plate, it adds sophistication to your bathroom with its sleek design. The dual flush buttons allow you to choose between a 6-liter full flush or a 3-liter half flush, promoting eco-friendly water usage. Elevate your bathroom experience by pairing the Geberit Sigma Cistern with the Sigma 20 Dual Flush Plate.
Product Details
- Cistern Width: 570mm
- Cistern Height: 510mm
- Cistern Depth: 205mm
- Flush Plate Dimensions: 246 x 164mm
- Flush Plate Colour: Chrome
- Button Shape: Circular
- Style: Modern
- For drywall construction
- For installation in part or room-height prewall installations
- For installation in room-height installation walls
- For floor-standing WCs
- WRAS Approved
- Front actuation
- Fully insulated against condensation
- Cistern fulfils standard requirements in accordance with EN 14055, Class II
- Flush bend fitted
- Tool-free installation and maintenance
- Water supply connection on the rear or top centre
- Protection cover box for service opening protects against moisture and dirt
- Protection box can be cut to length
- Flow pressure 0.1-10 bar
- Maximum operating temperature, water 25°C
- Flush volume, factory setting 5.8 and 3l
- Flush volume small, adjustment range 2-4l
Comprises:
- Sigma20 Chrome Dual Flush Plate
- Water supply connection Rp 1/2" - R 1/2", compatible with MF, with integrated angle stop valve and hand wheel
- Protection box for service opening
- Flush bend 90°
- Fastening for flush bend
- Protection plug
- 2 slotted flat irons
- 2 fixing brackets
- Fastening material
- Flush bend extension, ø 45mm
All measurements are approximate
